Dock Floats

Ace floating dock floats are available in standard, large and boatlift configurations providing buoyancy ratings from 230lbs to 4628lbs. Many different dock float sizes and float dock supplies are available to match any application you may be planning. Our floating dock floats and boat lift floats also provide features and benefits that continue to set them apart from other floating dock products, even those that look like ours. You can be assured that Ace dock floats meet the strictest specs and quality standards as well as having an unmatched warranty. That is why professional dock builders around the world choose Ace dock floats.

Meat and produce at the grocery store are priced on a cost per pound times a certified, measured weight basis. You can be confident that you are getting what you pay for. When shopping for dock floats, you should expect the same because what you’re really paying for is buoyancy pounds. However, most published buoyancy ratings are calculated based solely on outside dimensions of the float shell. Calculated buoyancy ratings can be as much as 20% higher than the actual buoyancy delivered.

Here is one example: An Ace 36x48x12 float delivers a certified tank-tested buoyancy rating of 656 lbs. The published buoyancy for a competitive float of the same dimensions is 679 lbs, but it actually delivers only 542 lbs (based on an equivalent tank test). That’s 20.2% less than published rating and 17.4% less than Ace’s equivalent float. Why pay 20% more for a float and actually get 20% less buoyancy? If your dock design is based on calculated buoyancy ratings, you may need to buy 20% more flotation to achieve your design goal. You won’t know that until you float your dock sections.

Don’t be fooled! Always ask for tank-tested buoyancy ratings.

Industry’s Only 15-Year Warranty

(1st 10 years at 100% Non-Prorated Replacement)

Ace floating dock floats are available in standard, large and boatlift configurations providing buoyancy ratings from 230lbs to 4628lbs. Fifty (54) different dock float sizes and float dock supplies are available to match any application you may be planning.

Our floating dock floats and boat lift floats also provide features and benefits that continue to set them apart from other floating dock products, even those that look like ours. You can be assured that Ace dock floats meet the strictest specs and quality standards. And our warranty is unmatched. That’s why professional dock builders around the world choose Ace dock floats.

Ace Dock Floats Exceed All Regulatory, Industry Tests and Environmental Standards for Design, Materials, Quality and Warranty

Not all dock floats are created equally. There are five components required to be the best dock float…

  • highest quality raw materials
  • field-proven float shell design
  • a void-free EPS foam fill
  • continuous quality testing of materials & completed dock floats
  • certified, tank-tested buoyancy ratings



Dock Float Sizes and Pricing

Sizes are shown in the table below with the fully submerged buoyancy rating and a PDF manufacturing drawing for each size.

We apologize for not being able to provide float pricing online. Actual delivered prices per float can vary significantly depending on your location, the location of our warehouses in relation to you, and the actual shipping costs in today’s fluctuating fuel market.

Some float sizes marked by an * can be shipped via FedEx Ground, while all other sizes must be shipped by common carrier.



Part No. Description Weight Dimensions Buoyancy
FF1248-20  Float Drum 26 12 x 48 x 20 359
FF1848-36 Float Drum 53 18 x 48 x 36 966
FF2072-08 Float Drum 33 20 x 72 x 08 360
FF2072-10 Float Drum 38 20 x 72 x 10 450
FF2096-10 Float Drum 49 20 x 96 x 10 592
FF2323-24RND* Cylindrical Float Drum 22 23 x 24 330
FF2436-08LF Log Float Drum 21 24 x 36 x 08 194
FF2436-08 Float Drum 20 24 x 36 x 08 211
FF2436-12 Float Drum 26 24 x 36 x 12 318
FF2436-16 Float Drum 29 24 x 36 x 16 436
FF2436-20 Float Drum 31 24 x 36 x 20 540
FFBM2448-12 Float Drum 30 24 x 48 x 12 409
FFBM2448-16 Float Drum 35 24 x 48 x 16 546
FF2448-08 Float Drum 26 24 x 48 x 08 288
FF2448-12 Float Drum 31 24 x 48 x 12 433
FF2448-16 Float Drum 37 24 x 48 x 16 581
FF2448-20 Float Drum 42 24 x 48 x 20 729
FF2448-24 Float Drum 49 24 x 48 x 24 866
FF2448-36 Float Drum 70 24 x 48 x 36 1297
FF2472-12 Float Drum 44 24 x 72 x 12 629
FF2472-16 Float Drum 57 24 x 72 x 16 796
FF2496-08 Float Drum 52 24 x 96 x 08 562
FF2496-12 Float Drum 64 24 x 96 x 12 866
FF2496-16 Float Drum 75 24 x 96 x 16 1155
FF2496-20 Float Drum 84 24 x 96 x 20 1420
FF3648-08 Float Drum 36 36 x 48 x 08 429
FF3648-12 Float Drum 43 36 x 48 x 12 650
FF3648-16 Float Drum 51 36 x 48 x 16 874
FF3648-18 Float Drum 52 36 x 48 x 18 990
FF3648-20 Float Drum 59 36 x 48 x 20 1088
FF3648-24 Float Drum 64 36 x 48 x 24 1280
FF3648-32 Float Drum 88 36 x 48 x 32 1644
FF3660-12 Float Drum 58 36 x 60 x 12 783
FF3660-16 Float Drum 61 36 x 60 x 16 1017
FF3660-20 Float Drum 74 36 x 60 x 20 1328
FF3672-12 Float Drum 60 36 x 72 x 12 999
FF3672-16 Float Drum 76 36 x 72 x 16 1313
FF3672-20 Float Drum 86 36 x 72 x 20 1638
FF3672-24 Float Drum 94 36 x 72 x 24 1951
FF3672-32 Float Drum 107 36 x 72 x 32 2553
FF3696-12 Float Drum 89 36 x 96 x 12 1331
FF3696-16 Float Drum 104 36 x 96 x 16 1735
FF3696-20 Float Drum 114 36 x 96 x 20 2172
FF3696-24 Float Drum 129 36 x 96 x 24 2597
FF3696-32 Float Drum 152 36 x 96 x 32 3349
FF3878-12 Float Drum 69 38 x 78 x 12 1133
FF4272-12 Float Drum 70 42 x 72 x 12 1166
FF4272-16 Float Drum 81 42 x 72 x 16 1555
FF4272-20 Float Drum 98 42 x 72 x 20 1934
FF4848-12 Float Drum 53 48 x 48 x 12 878
FF4848-16 Float Drum 65 48 x 48 x 16 1182
FF4848-20 Float Drum 75 48 x 48 x 20 1480
FF4848-24 Float Drum 83 48 x 48 x 24 1738
FF4848-32 Float Drum 108 48 x 48 x 32 2231
FF4848-36 Float Drum 114 48 x 48 x 36 2480
FF4860-12 Float Drum 69 48 x 60 x 12 1101
FF4860-16 Float Drum 79 48 x 60 x 16 1497
FF4860-20 Float Drum 91 48 x 60 x 20 1851
FF4860-24 Float Drum 103 48 x 60 x 24 2199
FF4860-32 Float Drum 130 48 x 60 x 32 2815
FF4872-12 Float Drum 77 48 x 72 x 12 1369
FF4872-16 Float Drum 95 48 x 72 x 16 1823
FF4872-20 Float Drum 108 48 x 72 x 20 2225
FF4872-24 Float Drum 118 48 x 72 x 24 2701
FF4872-28 Float Drum 141 48 x 72 x 28 2940
FF4872-32 Float Drum 153 48 x 72 x 32 3457
FF4872-36 Float Drum 166 48 x 72 x 36 3800
FF4884-12 Float Drum 89 48 x 84 x 12 1510
FF4884-16 Float Drum 105 48 x 84 x 16 2056
FF4896-12 Float Drum 102 48 x 96 x 12 1803
FF4896-16 Float Drum 124 48 x 96 x 16 2396
FF4896-20 Float Drum 141 48 x 96 x 20 2996
FF4896-24 Float Drum 157 48 x 96 x 24 3578
FF4896-32 Float Drum 188 48 x 96 x 32 4631
FF48120-12 Float Drum 124 48 x 120 x 12 2118
FF48120-16 Float Drum 143 48 x 120 x 16 3020
FF48120-20 Float Drum 176 48 x 120 x 20 3692
